LPe35004-M2 FC Host Bus Adapter 4 Port 32GFC Short Wave Optical – LC SFP+
| Specification | Value |
|---|---|
| Lifecycle | Active |
| Distributor Inventory | Yes |
| ECD Cable Support | 0.5m to 100m at 64GFC/32GFC on 50/125 µm OM4 MMF, 0.5m to 100m at 64GFC/32GFC on 50/125 µm OM5 MMF, 0.5m to 70m at 64GFC/32GFC on 50/125 µm OM3 MMF, 10 km at 32GFC/16GFC on 9/125 µm singlemode fiber when Emulex approved longwave transceivers are used |
| OS Support | Additional support is available from OEMs and partners, Microsoft Windows, Oracle Linux, Oracle Linux with the Unbreakable Enterprise Kernel (UEK), Oracle Solaris, Red Hat Enterprise Linux, SUSE® Linux Enterprise Server, VMware vSphere |
| Generation | Gen 7 (64/32GFC) |
| Hardware Environment | Intel x64, Intel x86, and PowerPC |
| Host Bus Type | PCIe Gen3 x16 |
| Industry Standards | Current ANSI/IETF Standards: FC-PI-4, FC-DA, FC-DA-2, FC-FS, FC-FS-3, FC-FS-4, FC-FS-5, FC-GS-2/3/4/5, FC-GS-6, FC-GS-7, FC-LS-2, FC-LS-3, FC-MI, FC-NVMe, FC-NVMe/AM1, FC-PH, FC-PH-2, FC-PH-3, FC-PI, FC-PI-2, FC-PI-3, FC-PI-4, FC-PI-5, FC-PI-6, FC-PI-7, FC-TAPE, FCP-2/3, FCP-4, Legacy ANSI/IETF standards: FC-PH, SBC-3, SPC-3, SPC-4, SSC-2, SSC-3, SSC-4 |
| I/O Controller | XE601 |
| Operating Humidity | 5% to 95% non-condensing |
| Operating Temperature [C°] | 0°C to 55°C |
| Optical Data Rates | 32GFC (28.05 GBaud NRZ), 16GFC (14.025 GBaud NRZ), 8GFC (8.5 GBaud NRZ), automatically detected |
| Optics | Optics Short wave lasers with LC type connector optics |
| Ordering Optional Accessories | LP32-LW-OPT-1 32GFC Optic (longwave laser with LC connector SFP+ transceiver): 1 pack, LP32-LW-OPT-2 32GFC Optics (longwave laser with LC connector SFP+ transceiver): 2 pack |
| Ordering Part # | LPe35004-M2 |
| Physical Dimensions | 111.15mm x 167.64mm (4.376” x 6.600”), Standard bracket |
| Ports | 4 |
| Regulatory Certifications | Australia(RCM), Japan(VCCI Class A), China(China RoHS Compliant), EU (Low Voltage Directive), EU RoHS compliant, Europe CE Mark, FCC Class A, Korea (KCC Class A), North America, Taiwan(BSMI Class A), UL/CSA Recognized |
| Storage Temperature | -20° to 85°C (-4° to 185°F) |
| Whats in the box |
Each box includes:
|
